Semi Automatic Non Woven Bag Making Machine
Salient Features
Automatic Pneumatic Controls
Easy operation With Pedal and switch both
Heavy built and robust to withstand heavy stroke
Ease to operate with touch screen in Double Decker model
Double Decker model can run on Single Mode as well
Branded pneumatic and electrical parts
Heavy Ultrasonic for proper sealing
Die has heater inside for strength sealing in laminated fabric as well
Easy size changing options
Sensor based technology for accuracy and speed.
Technical specifications
MODEL | FBX-200 | FBX-300 | FBXD-300 |
---|---|---|---|
Gusset Size | 3”-8” | 3”-12” | 3”-12” |
Bag width | 4”-16” | 4”-16” | 4”-16” |
Bag Height | 8”-20” | 8”-20” | 8”-20” |
Production Head | Single | Single | Double |
Production Speed | 6-15 pcs/min | 6-15 pcs/min | 10-30 pcs/min |
Weight(approx) | 330 kg | 350 kg | 400 kg |
Ultrasonic System | 20Khz | 15Khz | 15Khz |
Power Supply | 220v/1 phase/50hz | 220v/1 phase/50hz | |
Power | 2.5 Kw | 3 Kw | 3 Kw |
Size (LxWxH) | 800x350x450 | 800x350x450 | 800x800x450 |
Application | Non Woven, Laminated Non Woven, Bioplast, Woven Sack,Laminated Woven Sack etc. | ||
Touch/PLC | Optional | Optional | Yes |
Semi Leader Box Bag Making Machine
Non Woven Box Bag Industry is famous for premium quality of bags which has pictures on it for which majorly offset printed manually stitched non woven bags are more popular. Or else leader box bags are made from costly machines to attain production as by manual stitching quantity can not be attained. For which comes in the new developed and unique product by FAIRPRINT the Special Box Bag Making Machine also known as Semi Leader Box Bag Making Machine.
In Non Woven Industry Box bag Shape is considered most ethnic, classy and premium product and it has high profit margins as well. In this Semi leader Box Bag Making Machine one can make laminated or non laminated both non woven box bags. Not only that you can make offset printed box bag from this Special Double Decker Box Bag Making Machine without any hustle of reversing the bag and in increased productivity and quality.
In this FAIRPRINT have developed various model options of 8 inch gusset, 12 inch gusset and most productive model is Double Decker Box Bag Making Machine which can pe run by 2 persons for good production and in this structure is made so ergonomically that one can move his/her hands comfortably without any fear. And Also In Double Decker Machine there is a touch screen in which you can select single person or double person mode for example if there is one person to operate the machine that you can run machine on single mode as well that is the best part of this machine.
In Semi Leader Non Woven Box Bag Making Machine firstly bottom gusset bag which is printed from offset or flexo is taken if it is not creased for proper size one can easily get it creased from creasing machine. After that according to the gusset size there is die fixed in the machine, this die has special teeth and heater as well so that laminated non woven bag can also be formed in this Semi Automatic Leader Box Bag Making Machine. Further Bottom gusset bag is wear on the die and then pedal or button is pressed which begins the working of the machine and ultrasonic of super strength moves to seal the side edges of the bag. After that bags are removed from the machine and ethnic, classy box bag shape is attained which looks premium than manually stitched bags. So by increased production and powerful strength of bag one can attain more profit in non woven box bag shape and can deliver productivity in time.
Fairprint’s Double Decker box bag Making machine is a new invention of trend with productivity giving customer best option to boost his business with profit who are in this non woven industry, hence Fairprint has been awarded for this new launch at various events and exhibitions.
Applications
Box Type Non Woven Bag
Laminated Box Type Non Woven Bag
Box Type Bag Of Woven Sack
Box Type Bag Of Laminated Woven Sack
Box Type Bag Of CPP or Bopp etc.
Semi Leader Box Bag Making Machine
Process flow chart
1
Die With heater according to the size of gusset to be made is installed on machine
From Touch Screen Single Or Double Operation Mode is selected
2
3
Printed Bottom gusset Bag is wear over the die
Pedal or switch is pressed so that unit automatically moves in ultrasonic sealing portion
4
5
Ultrasonic stroke comes to seal the side of bag
Perfectly Box shape is formed
6
7
Bag is removed from machine and ethnic box shape bag becomes ready
Fairprint FAQ's
At what prices can we get the paper bag making machines?
At Fairprint, you can buy the best-in-class paper carry bag making machines at the most competitive prices. We have a team of experts who have designed the machines keeping in mind the manufacturing requirements of clients so that you can get the maximum value on the money invested.
Do you provide any after-sale support?
Being one of the leading paper bag making machine manufacturers, we are also known for our highly reliable after-sale support. Our team of technicians is always on the go to help clients deal with issues they are facing with our machines. We always work on resolving problems at the earliest to ensure that your organization’s productive hours do not get hampered.
Are these machines manufactured in India?
We strictly follow the concept of “Make in India” and do our part to contribute to the country’s economy. All our machines are manufactured in India using the latest parts that are assembled under the supervision of experts. If you want to bring excellence to your production unit, investing in our paper bag making and printing machines can be your best course of action.
What is the quality of output the machines deliver?
The machines are backed with state-of-the-art technology that, along with accelerating the pace of your production process, also uplifts the quality of the produced goods. The printing machines are equipped with advanced parts that ensure the highest print quality on different types of substrates. With these machines at your disposal, you never have to worry about quality.
Why Should We Use Reusable Grocery Bags?
Reusable Grocery bags are far better than plastic and paper bags. They are strong, reliable, eco-friendly, and durable that makes them the best choice for consumers.
