Semi Automatic Non Woven Bag Making Machine
Salient Features
Easy to operate with touch screen interface
Auto cut off system after roll finish
Automatic roll lifting arms
Hi-tech ultrasonic technology
Heavy rollers for high speed
High speed servo motors for immense speed
Heavy structure construction
Multiple bag shape options
Photo chromatic sensors, proximity sensor etc.
Double line production option
High quality pneumatic technology
Better accuracy and speed
Technical specifications
| Model | EH700 | EDH700 | EH800 | EDH800 |
|---|---|---|---|---|
| Fabric roll width (max) | 1250mm | 1250mm | 1550mm | 1550mm |
| Bag width | Flat bags- 100-1200
Vest bags 150-580 |
Flat bags- 100-1200
Vest bags 150-580 |
Flat bags- 100-1200
Vest bags 150-680 |
Flat bags- 100-1200
Vest bags 150-680 |
| Bag height | Flat bags- 150-580
Vest bags 100-1200 |
Flat bags- 150-580
Vest bags 100-1200 |
Flat bags- 150-680
Vest bags 100-1200 |
Flat bags- 150-680
Vest bags 100-1200 |
| Cutting blade width | 700mm | 700mm | 800mm | 800mm |
| Production speed | 40-120pcs/min | 40-120pcs/min | 40-120pcs/min | 40-120pcs/min |
| Non woven fabric thickness | 20-90 gsm | 20-90 gsm | 20-90 gsm | 20-90 gsm |
| Gusset | 25-85 mm | 25-85 mm | 25-125 mm | 25-125 mm |
| Power supply | 220v/1 phase/50hz | 220v/1 phase/50hz | 220v/1 phase/50hz | 220v/1 phase/50hz |
| Power | 11kw | 12kw | 12kw | 13kw |
| Side LxWxH) | 8000x2000x2000 | 8000x2000x2000 | 8000x2200x2300 | 8000x2000x2000 |
| Double w cut bag line | N/A | Yes | N/A | Yes |
| U cut/ w cut punching | N/A
|
N/A | N/A | N/A |
| Man power | 1 Skilled
1 unskilled |
1 Skilled
1 unskilled |
1 Skilled
1 unskilled |
1 Skilled
1 unskilled |
| High Speed Servo Motor | Yes | Yes | Yes | Yes |
High Speed Non Woven Bag Making Machine
The high speed non woven bag making machine has bring tremendous breakthrough in market of non woven industry, fairprint’s strong engineering and research team with the suggestions of the customers has brought path breaking high speed non woven bag making machine with unbelievable production capacity. Fairprint’s high speed non woven bag making machine is equipped with high speed servo motors, heavy structure, high speed rollers, ultrasonic, drives to attain the most efficiency from the machine and can produce large numbers in less time.
As day by day non woven market is becoming highly competitive, so with the help of this automatic high speed no woven bag making machine one can attain high profits, sustaining in the competitive market price by their increased production with same manpower used.
This fully automatic high speed non woven machine is embedded with advance PLC’s easy operative system, multiple bag options, size changing options etc. with almost double production. In major festivals in India like diwali, holi, rakshabandhan etc the demand of non woven bag is too high due to gifting items, sweets consumptions increases suddenly. In that duration the people are overloaded with the productions capacity of non woven machine, due to which sometimes they have order and still can’t fulfill them, for this here comes the high speed non woven bag making machine which increases the production and one can deliver things in time and with competitive market prices and attain more profit which makes this non woven bag making machine model the best seller in India. Not only this, the high speed non woven bag making machine also comes with a double line option in which one can get double productions of bags with high speed, that means firstly production doubles by high speed servo motors and secondly doubled by double line attachment. So the Highest production of approx. 4 times is attained by this double line high speed non woven bag making machine. Like other non woven bag making machine, this machine’s basic requirements is same servo stabilizer and air compressor.
In non woven high speed bag making machine the non woven roll runs from the roll feeding unit automatically than folded by the folder and guided by rollers and pulled by nipping rollers, further automatic d cut punching is done by pneumatic punching system and further side sealing is done by ultrasonic system and through panel the dimensions of bags are controlled and finally the batch of ready non woven bags are ready for packing and dispatch.
Applications
With high speed various types of non woven bag can be made by this fully automatic non woven bag making machine with high speed:-
D cut non woven bag
D cut non woven bag with bottom gusset
Dori/ string shoe bag of non woven
Pouches
Disposable pillow covers
Sheets/ palley/ napkins
Non woven election caps
Non woven flags and stoles
Vest bags/ u cut bags/ w cut bags/ t shirt bags/ baniyan cut bags/ jhola jhabla and various other names
Non woven bag with handle loop
Non woven bag with bottom gusset and handle loop
Non woven side gusset bag
Process flow chart
The high speed non woven bag making machine working can be well understood by the help of following chart
1
Roll feeded through lifter arms automatically
Mouth folding and ultrasonic sealing at same time
2
3
Roll passes to cubical folder and folded from center
D cut is punched pneumatically
4
5
Side sealing is done by ultrasonic horns and generators
Cutting of roll in desired dimension to form bag
6
7
Bas is ready to pack and dispatch
