Wall Printer
Single Pass Digital Printer
Salient Features
Low Print Cost
Easy Software for operation
Various Dpi Options
Hi-tech & Robust
Continuous no limit length printing possibility
4 Color and 5 Color options
Infrared sensor for locating incoming product
Auto adjustment up to 5mm according to rough surface
Multiple applications
Fast drying environmentally friendly ink
UV ink and Pigment ink option
Easy Customization and job changeover
Laptop or computer or touch computer compatible option for portability
Special guides for job path
Wheels for flat surface
Can run on track if floor in uneven
Compact portable design for easy transit
Electricity cut off same point resume option
(Note: there is no warranty of print heads)
Technical specifications
| Model | FSP-218 | FSP-436 | FSP-654 |
|---|---|---|---|
| Print Head (mm) | 218 | 436 | 654 |
| Conveyor Width (mm) | 600 | 800 | 1200 |
| Head type | Industrial grade Thermal Foaming Printhead | ||
| No. Of Heads | 1 | 2 | 3 |
| Printing speed | Upto 30 m/ min | Upto 30 m/min | Upto 30 m/min |
| Printing Resolution | 1200×300 dpi, 1200×600 dpi, 1200×1200 dpi | ||
| Height of head | 10-200 mm | 10-200 mm | 10-200mm |
| Flatbed type | Vacuum absorption, auto continual conveyor | ||
| Feeder | Optional | Optional | Optional |
| Print Media | Water absorbing material | ||
| Ink Type | Dye & Pigment Ink | ||
| Ink Tank | 500 ml/color | ||
| Ink Supply | Continuous ink supply system | ||
| Ink Color | CMYK | CMYK | CMYK |
| Image Type | JPEG, BMP, TIFF, PDF, AI, PSD, CDR etc | ||
| Operating Format | Win7, Win8, Win10, Win11 | ||
| Computer Configuration | 256 GB hard disk, and 8GB Ram | ||
| Working Condition | Temperature 10-30’C, Humidity 20-80%, Dust free | ||
| Power Supply | 220 V, 50 Hz | 220 V, 50 Hz | 220 V, 50 Hz |
| Power | 1 KW | 1.5 KW | 2 KW |
| Conveyor Operation Touch Screen | Yes | Yes | Yes |
| Language Interface | English | English | English |
| Manpower | 1 person | 1 person | 1 person |
| Size (LxWxH) mm | 1600x1250x1600 | 1600x1450x1600 | 1600x1900x1600 |
Note : No of heads and conveyor size can be customized according to the buyer requirement (there is no warranty of Heads)
Wall Printer
FAIRPRINT 3D Wall Printing Machine is a cutting-edge technology allows you to transform any wall into a masterpiece with stunning 3D designs. Whether you’re looking to add a unique touch to your home, office, or commercial space, our Digital Wall Printer is here to bring your vision to life.
With easy-to-use software, you can upload your own designs or choose from a library of options to create the perfect look for any room. This Digital 3D Wall Printer will elevate your design projects to the next level, revolutionizing the way you decorate your space. Our Wall Printer enables you to create stunning, high-definition designs directly on your walls, bringing your imagination to life. With its user-friendly interface and precise printing capabilities, this innovative technology allows for endless customization and personalization. Say goodbye to traditional wallpaper and hello to a new era of wall design with our Digital 3D Wall Printing Machine.
In this Wall printer which can be called as Wall pen or wall pencil is very easy to operate with the help of in-built computer or for easy compactness and ease to carry via laptop. The best part of this Wall printing machine is that is it can be folded and easily transported in boot of a car by easily folding car seats. And the weight of product is also not that high 2 persons can carry it through stairs on high-rise floors easily and these days lifts are very common so it can get into a domestic lift easily.
Another best function of Fairprint Digital Wall Printer is that if the floor is even it can run on wheels and if the floor is uneven it can run on tracks which are provided with the machine for better stability in printing. Easy transportation in compact pack and easy assembly at the site of printing makes it a unique wall robot which gives extra ordinary printing outputs as well, and when you will run the print command at client site they will be amazed not only by print quality but as well by the way there wall be turned into a master piece.
This Wall Printing Machine is very easy to use only one computer known person can operate it easily. In This Digital Wall Printing Machine firstly a design is imported in software where its size and color like cmyk or cmykw is converted into a prn file. This machine comes with both option 4 color printing or 5 colors printing if the surface on which design has to be printed is already colored one can use 5 colors printing so that it can print on colored surfaces as well by applying white color according to the design. After that this prn file is inserted in the operating software in which print command is given according to the starting point from where printing has to be done. Further the machine function starts automatically and the desired design is printed by this wall robot. The versatility of this wall printing robot makes it more popular as one can print not only on walls, but can also on mirror, wood, tile, metal etc. With these capabilities Fairprint wall printer has got huge demand in market because of its unique futuristic capabilities and one can earn a lot with his/her unique ideas to flow to reality.
Applications
Walls
Tiles
Wood
Metal
Glass
Almirah
Indoor and outdoor both
Blinds
Doors etc.
Single Pass Digital Printer
Process flow chart
1
Printer is assembled easily at the site
Job to be printed is imported in the software
2
3
According to the surface to be printed job is converted into 4 color or 5 color(if surface is colored)
The desired size of job is set in the software
4
5
File is exported to the printing software
Start point of job is set in the printing software
6
7
Print command is given
7
Multicolor digitally printed product comes out
